8000 Series Videokits with Codelock
1 and 2 button 8000 series colour videokits. The flexible design allows for the addition of up to a total of 4 entrance doors (using additional 506N relays) and up to 4 video handsets per call button with intercommunication between the handsets in the same apartment or video handsets in different apartments.
The video entry panels (8833-1/C and 8833-2/C) incorporates a high quality colour camera with auto iris lens and white illumination LED’s. The system does not require coaxial cable as it uses a balanced video pair V1 and V2. The camera module also has a unit address adjustment (for 4 door setup), conversation time and reassurance tone controls. The entry panel also includes a 2 code, 2 relay codelock module (8800) with keypad illumination LED’s.
The videokits are available as surface or flush videokits with an aluminium surround and front support frame finish or a black surround and front support frame finish (suffix /BL). The videokits are available with either of the following videophone/hands free monitor options: 6256 videophone, 6358 hands free monitor, 6458 hands free monitor or 6758 hands free monitor. Features of both videophone and hands free monitors include an adjustable 3 level call tone, camera recall (selectable), timed privacy facility with LED indication.
Features
- Surface or flush 1 or 2 button videokit options
- Kits available with either a 6200 series videophone, 6300 series, 6400 series or 6700 series hands free monitors
- Expandable up to 4 entrances (with additional 506N relays)
- Call a total of 4 videophones/hands free monitors off each call button
- Intercommunication between videophones in same apartment or between different apartments
- 2 code, 2 relay codelock module with keypad illumination LED's
Technical Details
- Number of entrances: 1 (Expandable to 4 using additional 506N relays)
- No. Of cores to videophone: 6 from panel, 2 from PSU
- Recommended cable type: CW1308
- Maximum number of call buttons: 2
- Maximum No. Of videophones per call button: 4
- Lock output: 12Vdc capacitive discharge feature or dry contact (C, NO and NC)
- Videophone models: 6256 videophone, 6358, 6458 or 6758 hands free monitor
- PSU model: 850K (1x psu required per videophone/hands free monitor)
- Additional PSU model: 323/18 (1 per additional door panel)
- Speaker/camera module: 8833-1/C or 8833-2/C
- Codelock module: 8800 (2 code, 2 relay – 1 code per relay)
- Mounting options: Surface or flush
- Entry panel finishes: Aluminium surround and front support frame or black surround and front support frame
Product Variants
Flush Videokits
- CVKC8K – 8000 series, 1 way flush colour videokit and codelock with 6256 videophone
- CVKC8K/6358 – 8000 series, 1 way flush colour videokit and codelock with 6358 hands free monitor
- CVKC8K/6458 – 8000 series, 1 way flush colour videokit and codelock with 6458 hands free monitor
- CVKC8K/6758 – 8000 series, 1 way flush colour videokit and codelock with 6758 hands free monitor
- CVKC8K2 – 8000 series, 2 way flush colour videokit and codelock with 2x 6256 videophones
- CVKC8K2/6358 – 8000 series, 2 way flush colour videokit and codelock with 2x 6358 hands free monitors
- CVKC8K2/6458 – 8000 series, 2 way flush colour videokit and codelock with 2x 6458 hands free monitors
- CVKC8K2/6758 – 8000 series, 2 way flush colour videokit and codelock with 2x 6758 hands free monitors
Surface Videokits:
- CVKC8KS – 8000 series, 1 way surface colour videokit and codelock with 6256 videophone
- CVKC8KS/6358 – 8000 series, 1 way surface colour videokit and codelock with 6358 hands free monitor
- CVKC8KS/6458 – 8000 series, 1 way surface colour videokit and codelock with 6458 hands free monitor
- CVKC8KS/6758 – 8000 series, 1 way surface colour videokit and codelock with 6758 hands free monitor
- CVKC8K2S – 8000 series, 2 way surface colour videokit and codelock with 2x 6256 videophones
- CVKC8K2S/6358 – 8000 series, 2 way surface colour videokit and codelock with 2x 6358 hands free monitors
- CVKC8K2S/6458 – 8000 series, 2 way surface colour videokit and codelock with 2x 6458 hands free monitors
- CVKC8K2S/6758 – 8000 series, 2 way surface colour videokit and codelock with 2x 6758 hands free monitors
The entry panel finish for all the videokits listed above are for the aluminium surround and front support frame version. For the black surround and front support frame finish suffix /BL to the part code e.g. CVKC8KS/BL.
All 2 way (2 button) videokits are supplied with a 316N balanced video distribution box.
