Paxton Proximity Marine Reader 500-010

Box contents

	Plastic - marine reader back plate gasket
	Fitting kit - Marine reader
	Packaging - box insert - ACU's for icc-bx01 (cui)
	Packaging - box OD 190x175x55mm readers (ne3)
	Label - product serial number label 27x10mm
	Label - Void if seal is broken, 80x30mm
	Label - ICASA outer box label
	Sales Code label, 27x20mm, Paxton EX, CE, ICASA
	Metalwork - slotted marine reader backplate SS316
	Bubble pouches large - antistatic
	Backlight dimming card
	Net2 Marine proximity reader 2nd Gen

Specifications - Proximity marine reader
	min	typ	max	units
Electrical
Operating voltage	10	12	14	V DC
Current consumption	130		220	mA
Carrier frequency		125		kHz
Clock & data bit period		600		µs
System Specification
Cable type for extensions		Belden 9540
Max cable extension length			100	m
Read range: Keyfob			30	mm
Read range: Token/ISO card			40	mm
Read range: Watchprox			20	mm
Read range: Hands free tokens			400	mm
Additional coloured bezels available		No
Net2Air compatible		Yes
Environment
Operating temperature	-35		70	°C
Moisture resistance		IPX7
Vandal resistance		Medium
Dimensions
Diameter		106		mm
Depth		16		mm
