Videx KL7VXIPB Black Klass 7" Colour Touch Screen Handsfree Video Monitor
Klass Series videointercom, Embedded Linux operating system, 7” 16/9 high resolution (1024x600 pixels IPS) LCD TFT full touch capacitive touchscreen, 3mm glass cover lens, full-duplex audio speaker, temperature/humidity sensor, ambient light sensor, proximity sensor, 2 active/low inputs, 2 relay outputs that can be activated locally (C, NO - max 35Vdc 50mA), 8 soft-touch buttons that can be configured or dedicated to preset functions: conversation/auto power on, door opener, intercom call, video camera/privacy service switching, etc. Contrast adjustment, brightness and call volume.
Local call input, video-intercom function configurable through GUI menu (up to 1080p).
Features:
- Privacy programmable through GUI menu, weather widget, switching outdoor audio/video stations or CCTV video cameras implemented with RTSP protocol, event log available locally or through the Videx APP, CCTV implementation with PiP feature.
- Smart chronothermostat function that can be managed locally or through the Videx APP. Integrated browser, Multi-compatibility with protocols: SIP 2.0, RTSP, HTTP.
- Optional Wi- Fi Dongle module Cod. DNGL. Bracket Cod. KLBRB. is included.
- White glass and ABS material. RJ-45 port 10/100 Mbps. IEEE 802.3af (Class 0) PoE power or 12V dc - 650mA.
- Dimensions: 195x165x30mm.
- Wall-mounted, optional table stand Code. KLHFTS or Code. KLHSTS.
Technical Specifications:
| Display |
7” 16/9 high resolution (1024x600 pixels IPS) LCD TFT full touch capacitive touchscreen |
| Handset/Hands free |
Hands free or Handset (require Cod. KLHSB) |
| Front plate |
3mm glass cover lens |
| Built-in camera |
Hi-res up to 1080p colour camera |
Buttons
(Default settings) |
8 soft touch backlit push buttons, all programmable for direct controls (Service, Camera recall, Door-open/Intercommunicating call, Privacy) |
| Privacy |
Yes, timed |
| Operating system |
Linux OS |
| Video streaming |
From external IP cameras H.264, H.265 and MJPEG |
| Open protocol |
HTTP (API), SIP 2.0 (VOIP), RTSP |
| Programmings |
Service, Privacy duration, Number of rings, Intercommunicating call, Melody type, Door panels phonebook |
| Interfaces |
10/100 Mbps Ethernet, Optional WiFi dongle connection |
| CCTV compatibility |
Yes, IP-based with RTSP |
| Sensors |
Proximity sensor for user presence detection
Brightness sensor for automatic screen brightness adjustment, for automatic switching to light/dark theme and for home automation
High quality integrated temperature and humidity sensors (Smart chronothermostat) |
| SIP compliant |
Yes |
| Induction coil for hearing aid users |
Yes |
| RJ-45 plug |
Yes |
| Inputs |
2 programmable active low inputs |
| Outputs |
2 programmable dry contacts |
| Power supply |
PoE (802.3af Class 0 - 12.95W) or 12Vdc |
| Mounting |
Surface or tabletop (require Cod.KLHFTS or Cod.KLHSTS) |
| Finishes |
Black |
