VR4K Multi Apartment Video Kits
3 – 12 way vandal resistant 4000 Series video kits based on the VX2200 non-coax 6 wire video system. Door panels have 3 call progress LEDS: “Call in progress”, “Speak” and “Door open”. The day/night colour CCD camera is wide angle and illuminated using infra-red LED’s.
Included in the kit is a 6000 Series videophone with a 3.5″ high definition LCD TFT colour display, camera recall facility, door open button, 2 spare service buttons with LED indication, Privacy, 2 level call tone adjustment and contrast / brightness controls.
A maximum 3 videophones may be called from a single button.
Features
- 3 - 12 button colour video kits based on the vandal resistant 4000 Series
- Surface or flush mount door panel
- Colour CCD day/night camera with infra-red illumination
- Expandable up to 10 entrances
- Call a total of 3 videophones off each call button
Technical Details
- Number of entrances – 1 (Expandable to 10)
- No. Of cores to videophone – 6
- Recommended cable type – CW1308
- Maximum number of call buttons – 12
- Maximum No. Of videophones per call button – 3
- Lock output – 12Vdc or dry contact
- Videophone model – 6276
- Amplifier module – VR4KAM
- Camera module – VR4KCMC
- System type: Vx2200
Product Variants
- CVR4KV-3 – 3 way flush colour video kit
- CVR4KV-4 – 4 way flush colour video kit
- CVR4KV-5 – 5 way flush colour video kit
- CVR4KV-6 – 6 way flush colour video kit
- CVR4KV-7 – 7 way flush colour video kit
- CVR4KV-8 – 8 way flush colour video kit
- CVR4KV-9 – 9 way flush colour video kit
- CVR4KV-10 – 10 way flush colour video kit
- CVR4KV-11 – 11 way flush colour video kit
- CVR4KV-12 – 12 way flush colour video kit
- CVR4KV-3S – 3 way surface colour video kit
- CVR4KV-4S – 4 way surface colour video kit
- CVR4KV-5S – 5 way surface colour video kit
- CVR4KV-6S – 6 way surface colour video kit
- CVR4KV-7S – 7 way surface colour video kit
- CVR4KV-8S – 8 way surface colour video kit
- CVR4KV-9S – 9 way surface colour video kit
- CVR4KV-10S – 10 way surface colour video kit
- CVR4KV-11S – 11 way surface colour video kit
- CVR4KV-12S – 12 way surface colour video kit
