Focus Range 4Mp H265 IP Ir Bullet Camera With 2.8-12Mm Auto Focus Lens

The Genie PWIP4BVAFG are 4MP IP IR bullet cameras with a 2.8-12mm varifocal auto focus lens. The cameras also feature up to 50m IR night view distance as well as being IP67.

NDAA compliant
4MP (2560 x 1440) H.265 coding
Maximum resolution: 2560 x 1440
ICR auto switch, true day / night, ROI coding
3D DNR, digital WDR, HLC, BLC, defog
30~50m IR night view distance
Supports remote monitoring by smart phones and tablet PCs with iOS and Android OS
DC12V / PoE power supply
IP67 ingress protection
Supports three streams
Intelligent analytics : Object removal detection, abnormal video signal detection, line crossing detection and region intrusion
detection

Image Sensor	1 / 2.7 “CMOS
Image Size	2560 x 1440
Electronic Shutter	1 / 25 s ~ 1 / 100000 s
Iris Type	Fixed Iris
Minimum Illumination	0.011 Lux @ F1.2, AGC ON, 0 Lux with IR 0.04 Lux @ F2.26, AGC ON, 0 Lux with IR
Lens	2.8~12mm @ F1.4, Horizontal field of view: 94°~35.7°
Lens Mount	M12 or Φ14 optional
Wide Dynamic Range	Digital WDR
BLC	Yes
HLC	Yes
Defog	Yes
Digital NR	3D DNR
Angle Adjustment	Pan: 0°~360°,Tilt: 0°~90°, Rotation: 0°~360°
Video Compression	H.265, H.264
H.265 Compression Standard	Main Profile @ Level 4.1 High Tier
Resolution	4MP (2560 x 1440), 3MP (2304 x 1296), 1080p (1920 x 1080), 720p (1280 x 720), D1, CIF, 480 x 240
Main Stream	60Hz: 4MP, 3MP, 1080p (1~30fps) 50Hz: 4MP, 3MP, 1080p (1~25fps)
Sub Stream	60Hz : 720p (1~15fps), D1 (1~30fps), CIF (1~30fps) 50Hz: 720p (1~12fps), D1 (1~25fps), CIF (1~25fps)
Bit Rate	64 Kbps ~ 5 Mbps
Bit Rate Type	VBR / CBR
Image Settings	ROI, Saturation, Brightness, Chroma, Contrast,Wide Dynamic, Sharpen, NR, etc. adjustable through client software or web browser
ROI	Each ROI to be configured separately
Remote Monitoring	Web browsing, CMS remote control
Online Connection	Supports simultaneous monitoring for up to 4 users. Supports multi-stream real time transmission
Network Protocol	UDP, IPv4, IPv6, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP, 802.1x, UPnP, HTTP, HTTPs, QoS
Interface Protocol	Onvif compatible
Intelligent Analytics	Region intrusion detection, Object removal detection, Abnormal video detection, Line crossing detection
Smart Alarm	Motion detection
General Function	Watermark, IP address filtering, video mask, heartbeat, password protection
PoE	Yes
IR Distance	30 ~ 50 m
Network Interface	RJ45
Video Output	No
Audio	No
Storage	No
Hardware Reset	No
Ingress Protection	IP67
Power Supply	DC12V / PoE
Power Consumption	< 9W
Operating Environment	– 30°C ~ 60°C (-22°F~140°F), Humidity: Less than 95 % (Non-condensing)
