| Weight | 0.54 kg |
| Camera Image Sensor | 1/2.8 “CMOS |
| Camera Image Size | 3840 x 2160 |
| Camera Electronic Shutter | 1/3s ~ 1/100000s |
| Camera Iris Type | Fixed Iris |
| Camera Minimum Illumination | 0.02 lux @F1.6, AGC ON; 0 lux with illumination on |
| Camera Lens | 2.8mm@F1.6, Horizontal FoV: 94°; Vertical FoV:50°; Diagonal FoV:115° |
| Camera Focus | Fixed |
| Camera Lens Mount | M12 |
| Camera Day&Night | ICR |
| Camera Wide Dynamic Range | 120dB |
| Camera BLC | Yes |
| Camera HLC | Yes |
| Camera Digital NR | Yes |
| Camera S/N Ratio | ≥50dB |
| Camera Angle Adjustment | Pan: 0°360°; Tilt:0°75°; Rotation: 0°~360° |
| Image Video Compression | Main stream: H.265+ / H.265 / H.264+ / H.264
Sub stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG
Third stream: H.265+ / H.265 / H.264+ / H.264/ MJPEG |
| Image H.265 Compression Standard | Main Profile@Leve4.1 High Tier |
| Image Resolution | 8MP (3840×2160), 6MP (3200×1800) ,1080P (1920×1080), 720P (1280×720),
D1, VGA (640 × 480), CIF, 480 × 240 |
| Image Main Stream | 60Hz: 8MP(120fps)
/6MP/4MP/2K/1080P (130fps)
50Hz: 8MP(120fps)
/6MP/4MP/2K/1080P (125fps) |
| Image Sub Stream | 720P/D1/VGA/640×360/CIF/480× 240
(60Hz: 130fps; 50Hz: 125fps) |
| Image Third Stream | 720P/D1/640×360/CIF (60Hz: 130fps;
50Hz: 125fps) |
| Image Bit Rate | 64 Kbps ~ 6 Mbps |
| Image Bit Rate Type | VBR/CBR |
| Image Settings | ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Sharpness, Image Mirror,
Image Flip, NR, etc. adjustable through client software or web browser |
| Image ROI | Each ROI to be configured separately |
| Image Audio Compression | G711A/U |
| Remote Monitoring | Web browser /NVR/NVMS2.X/Mobile APP |
| Web Browser | IE (plug-in required)/Google Chrome/Edge/Firefox/Safari |
| Online Connection | Support simultaneous monitoring for up to 3 users; Support multi-stream real time transmission |
| Network Protocol | UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, RTMP, PPPoE, DDNS, SMTP, FTP,
802.1x, SNMP, UPnP, HTTP, HTTPS, HTTP POST, QoS |
| Interface Protocol | ONVIF |
| Storage | Network remote storage, micro-SD card storage |
| Smart Alarm | Motion detection, SMD, SD card full, SD card error |
| Smart Event | Video Exception (scene change, video blur and abnormal colour detection),
Line crossing /region intrusion detection(human/motor vehicle/non-motor vehicle classification),
Abandoned/missing object detection |
| General Function | Watermark, IP address filtering, video mask, heartbeat, system config backup,
Smart supplement light, Corridor pattern |
| PoE | Yes |
| Supplement Light Range | IR range: 20 ~ 30 m;
White light range: 20 ~ 30 m |
| Ingress Protection | IP67 |
| Security | Video encryption, firmware encryption, configuration encryption,
Illegal login lock, IP address filtering, 802.1x authentication, basic and digest authentication for HTTP |
| Network Interface | RJ45 |
| Video Output Interface | No |
| Audio Interface | 1Channel audio input; 1Channel built-in MIC |
| Storage Interface | Built-in micro-SD card slot, up to 256GB |
| Hardware Reset Interface | Yes |
| DORI Interface | Lens 2.8mm – Detect 62m(203ft) Observe 25m(81ft) Recognize 12m(40ft) Identify 6m(20ft) |
| Power Supply | DC12V/PoE |
| Power Consumption | < 6W |
| Storage Conditions | – 30 °C ~ 65°C (-22°F~149°F), Humidity: less than 95 % (non-condensing) |
| Operating Environment | – 30 °C ~ 60 °C (-22°F~140°F), Humidity: less than 95 % (non-condensing) |
| Dimensions | Φ 94.6 × 82.8mm |
| Weight | Approximately 0.45KG |
| Installation | Ceiling mounting; Wall mounting |
