The shock sensors can be connected directly to control panels that have zones with incorporated analysing faciliities or can be used in conjuction with dedicated analyser boards (GS614 and GS615). In both cases, the analysing capability has two separate detection criteria: gross attack and pulse count. The gross attack threshold is designed to react to a single blow. While pulse count triggers an alarm when a pre-selected number of smaller shocks, occuring within a 30 second timing interval is reached.
Superior Detection
Its unique design enables the shock sensor to discriminate between a real break-in attempt and everyday background noise by measuring the shock frequency caused by the displacement in the protected structure. The sensor is designed to activate (contact will open) when an acceleration greater than 1G is detected. This could be caused, for example by a strong blow, a high speed drill or sawing because the frequencies of these shocks fall within the sensors range of detection.
Details
- Reliable 24 hour loop perimeter protection
- Superior technology provides excellent detection and false alarm immunity
- Suitable for all types of solid structures
- Versatile mounting through 360° axis
- 24 carat gold plated internal mechanics for optimum performance & long life
- Available analysers; GS614 & GS615
Technical Specifications
Product type - Shock, Magnetic Contact
Detection - Range Up to 6 m Wired
Physical
Physical dimensions - 72 x 30 x 28 mm
Colour - White
Environmental
Operating temperature - -40 to +50°C
Detection range Up to 6 m
LED indication No
Colour White
Dimensions (W x H x D) - 72 x 30 x 28 mm
Reed switch - Yes
Operating gap - 16 mm
