Voltek One Channel Door Contact Interface

The Voltek DCI-1 One Channel Door Contact Interface allows a suitable magnetic door contact (that contains no electrical components) to be used in a hazardous area.



Key Features

  • Allows a suitable magnetic door contact (that contains no electrical components) to be used in a hazardous area.
  • Normally open or normally closed relay outputs available for each channel
  • LED status indicator
  • Supplied complete with installation instructions
  • Suitable for both external and internal use - but must be mounted in a safe area



Technical Specification

Operating Voltage24VDC
Current Consumption40mA max per single channel barrier
60mA max per double channel barrier
Relay ContactNormally open / normally closed with phase reversal
Relay V Max35VDC
Relay I Max0.5A
Operating Temperature5°C - 40°C
WeatherproofingIP65 (cable entries permitting)
Enclosure Size (w x h x d)300mm x 200mm x 130mm
Weight2.0KG max
Pack ContentsInterface Unit and installation instructions
  • Model: DCI-1
  • Shipping Weight: 2 kgs
  • Manufactured by: Voltek
