Eaton 4G/2G Comms module with Adapter

larger image

Obsolete

Alternative click here

The 4G Cloud Communicator is a plug-on module that allows a control unit to access the Eaton SecureConnect™ service over the internet using 4G and 2G mobile phone networks.

It enables access to our Installer cloud portal and end-user app without the need for the customer to have existing internet access in the premises.

In addition to having the fastest mobile data communication we have ever provided it also offers backup connection through the 2G network providing further redundancy all from one simple plug-on device.

TECHNICAL SPECIFICATIONS

Power supply:    12Vdc; 240mA (max. when active); 15mA quiescent.
Dimensions:    62 x 40 x 12mm (HxWxD)
Weight:    18g
Operating temperature:    -10°C to +55°C
Humidity:    0-93% non-condensing
Environmental:    Class II
4G capaability:    Tri-band LTE,1800MHz (B3), 900MHz (B8) and 800MHz (B20); Max power 25dBm
2G capability:    Dual-band GSM/GPRS/EDGE (900MHz and 1800MHz); Max power 2W
Antenna:    Built-in, and MMCX connector for external antenna
Intrusion standards:    EN 50131-10:2014; EN 50136-2:2013
ATS Class:    EN 50136-2 SP2
SIM card:    Micro SIM (3FF)
Mobile network:    Requires a data SIM card and network provider that supports 2G and 4G
