Knight Black Grade 3 Shock Sensor and Tilt Sensor (Advanced)

• Grade 3

• Black housings

• Complies with the brand new EN50131-2-8:2016 standard

• Sensitivity Auto calibration

• Sensitivity pot

• Selectable EOL and Alarm resistors

• Rear tamper detection (meeting G3)

• LED enable jumper

• Suitable for mounting in the ‘V BOX’

• Pulse count selectable on board

• Pulse count selectable via serial link

• Vibration and surface / tilt detection selectable on board

• Motion sensing available on any movement along the vertical plane

• Vibration and surface / tilt detection selectable via serial link

• Fault output

• Selectable Fault resistors

• Latch terminal

• First to Alarm memory

• Remote LED enable

• Heartbeat LED

• Serial connection option

• EOL Resistor options: 1k,2k2,4k1,4k7,5k6

• Alarm Resistor options: 1k,2k2,4k1,4k7,5k6,6k8

• Fault Resistor options: 2k2,3k,6k8,12k

• Dimensions(mm): 88 x 25 x 22.8

• Also available in White or Brown – please contact us for further details

NOTE: SEISMO ADVANCE DOES NOT SUPPORT FULLY EOL MONITORED WIRING IN SERIES / SHARED ZONE CONFIGURATION.  THIS CAN BE ACHIEVED VIA THE LATCHING FUNCTION, USING 4 WIRE CONFIGURATION
